TBI TRH20VN Standard type Linear Ball Bearing TBIMOTION H20VN Linear Block

Brand Name : TBI

Model Number : TRH20VN

Certification : ISO90001

Place of Origin : Taiwan,China

MOQ : 1.PCS

Price : Negotiable

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 1000.pcs / Month

Delivery Time : Within 3 days

Packaging Details : Standard Carton Box

Material : stainless steel

Type : standard type linear block

Stock Qty : 125.pcs

Weight : 0.05 KG

Contact Now

TBI TRH20VN Standard type Linear Ball Bearing TBIMOTION H20VN Linear Block

1. Type: standard type linear ball bearing

2. Specification:

Part number	TRH20VN
Slide height	30 mm
Slide length	44 mm
Slide width	75.6 mm
Mass	0.3 kg

3. Feature:

(1) TBI Taiwan made

(2) Stainless steel material

(3) Standard type

(4) Normail accuracy

(5) Low noisy

(6) Corrosion resistance possible

4.Flange type: without flange

5.Height of assembly type:

S: Low- assembly

C: Middle-assembly

H: High-assembly

6.Quality guarantee: 1 year

7.Transportation type: by express or by air

8.Application: CNC machine,precision equipments and so on

9,Bearing photos:

TBI TRH20VN Standard type Linear Ball Bearing TBIMOTION H20VN Linear Block

Besides,we also have the models given as below in Stock:

Part number	Slide Heigh(mm)	Slide Width(mm)	Slide Length(mm)
MGW5C	6.5	17	20.5
MGW7C	9	25	31.2
MGW7H	9	25	41
MGW9C	12	30	39.3
MGW9H	12	30	50.7
MGW12C	14	40	46.1
MGW12H	14	40	60.4
MGW15C	16	60	54.8
MGW15H	16	60	73.8

If you want to buy TBI TRH20VN linear block,please send inquiry to tommy@gqbearing.com
